RA is a backward transmission signal amplifier by utilizes Raman effects. This product can be widely us ed in SDH, DWDM and other long-distance transmission scenarios. It can not only amplify the optical signal, but also improve the OSNR (Optical Signal-to-Noise Ratio) of the system and significantly extend the transmission distance.
RA is a backward transmission signal amplifier by utilizes Raman effects. This product can be widely us ed in SDH, DWDM and other long-distance transmission scenarios. It can not only amplify the optical signal, but also improve the OSNR (Optical Signal-to-Noise Ratio) of the system and significantly extend the transmission distance.
Lower noise index；
High Gain, low power consumption
Support automatic shutdown and provide higher safety guarantee；
High integration with 2 slots available in STN6200;
Higher reliability
|
Parameters |
Descriptions |
|
Wave length |
1550nm or 1529nm～1561nm |
|
Receiving Power |
-38~-10dBm |
|
Gain |
15dB or 25dB |
|
Noise Index |
-3dB |
|
Width |
2 Standard Slots |
|
Max Power Consumption |
40W |
|
Interface Type |
LC/UPC |
